SFP56-50G-SR 50G SFP56 SR 850nm PAM4 Duplex LC MMF 100m Dual CDR DDM Optical Transceiver Module

QSFP28 series optical transceiver include LR, ER, LR BI-DI and so on. This series of products adopt PAM4 modulation technology, with a single channel rate up to 53.125Gb/s. It has the characteristics of low power consumption, small size and high reliability, and is mainly used for telecommunication network transmission and 5G medium transmission.
  • 50G SFP

  • Keweifiber

Availability:
Quantity:
sharethis sharing button
  • Hot pluggable QSFP28 MSA form package, QSFP28 MSA compliant

  • Supports 53.125Gb/s data rate

  • +3.3V power supply

  • I2C management interface

  • RoHS compliance

  • Operating temperature range: 0~70°C(Commercial) /-40~85℃(industrial)



P/N
Description
Data Rate
Reach
Tx
Rx
Output Power(OMA)
Sensitivity(OMA)

KWQG10

QSFP28 LR
50Gb/s
10Km
1310nm DML
PIN
-1.5~+4.0dBm
≦-8.4dBm

KWQG40

QSFP28 ER
50Gb/s
40Km
1310nm EML
APD
+3.4~+7.4dBm
≦-15.1dBm

KWHG10-2733

QSFP28 LR BiDi
50Gb/s
10Km
1270nm DML
1330nm PIN
-1.5~+4.0dBm
≦-8.4dBm

KWHG10-3327

QSFP28 LR BiDi
50Gb/s
10Km
1330nm DML
1270nm PIN
-1.5~+4.0dBm
≦-8.4dBm

KWHG40-2930

QSFP28 ER BiDi50Gb/s40Km1295nm EML1309nm APD+3.4~+7.4dBm≦-15.1dBm

KWHG40-3029

QSFP28 ER BiDi50Gb/s40Km1309nm EML1295nm APD+3.4~+7.4dBm≦-15.1dBm

KWHG10-3131

QSFP28 LR BiDi50Gb/s10Km1310nm EML1310nm PIN-1.5~+4.0dBm≦-8.4dBm

KWHG40-3131

QSFP28 ER BiDi50Gb/s40Km1310nm EML1310nm APD+3.4~+7.4dBm≦-15.1dBm
