Cisco SFP-25G-SR-S Compatible 25GBASE-SR SFP28 850nm 100m DOM Duplex LC MMF Optical Transceiver Module

The 25G SFP28 series optical transceiver include SR, LR, ER, CWDM, DWDM, LWDM, MWDM and so on. This series of optical transceivers use LC optical interface, with low power consumption, small size, high reliability, wide temperature range and other characteristics, mainly used in data center server access, 5G fronthaul.
  • 25G SFP

  • Keweifiber

Availability:
Quantity:
sharethis sharing button
  • Hot pluggable SFP28 MSA form package, SFP28 MSA compliant

  • +3.3V power supply

  • Supports 25.78Gb/s data rate

  • I2C management interface

  • RoHS compliance

  • Operating temperature range: 0~70°C(Commercial) /-20~85℃(Extended)/-40~85℃(industrial)





P/N Description Data Rate Reach Tx Rx Output Power Sensitivity
KW3001D


SFP28 SR 25Gb/s
100m
850nm VCSEL
PIN
-7.0~+2.4dBm
≦-10.3dBm
KW3003DSFP28 LR Lite 25Gb/s 300m 1310nm DFB PIN -6.8~+2.0dBm ≦-10.5dBm
KW3010D
SFP28 LR 25Gb/s
10Km
1310nm DFB
PIN
-7.0~+2.0dBm
≦-12.0dBm
KW3030D
SFP28 ER Lite
25Gb/s
30Km
1310nm DFB
APD -3.0~+6.0dBm
≦-19.0dBm
KW3040D
SFP28 ER
25Gb/s
40Km
1310nm EML
APD --3.0~+6.0dBm
≦-19.0dBm
KW5010D-2733SFP28 Bi-Di25Gb/s10Km1270nm DFBPIN-5.0~+2.0dBm≦-12.0dBm
KW5010D-3327
SFP28 Bi-Di
25Gb/s
10Km
1330nm DFB
PIN
-5.0~+2.0dBm
≦-12.0dBm
KW5030D-2731
SFP28 Bi-Di
25Gb/s
30Km
1270nm DFB
APD
0~+6.0dBm
≦-19.0dBm
KW5030D-3127
SFP28 Bi-Di
25Gb/s
30Km
1310nm DFB
APD
0~+6.0dBm
≦-19.0dBm
KW3010D-xxSFP28 CWDM
25Gb/s
10Km
1271~1371nm DFB
PIN
0~+7.0dBm
≦-14.1dBm
KW3015D-xxSFP28 CWDM25Gb/s15Km1271~1371nm DFBAPD0~+7.0dBm≦-19.6dBm
KW3010D-DXXSFP28 DWDM
25Gb/s
10Km
DWDM ITU EML
PIN
-3.0~+6.0dBm
≦-12.0dBm
KW3010DI-LXXX
SFP28 LWDM
25Gb/s
10Km
LWDM DFBPIN
+2.0~+7.0dBm
≦-14.0dBm
KW3010DI-MXXX
SFP28 MWDM
25Gb/s
10Km
MWDM DFBPIN
+2.0~+7.0dBm
≦-14.0dBm
