Discription: Outdoor fiber optic Terminal box, 6 splice tray for 144 FO splice capacity,8 open cable ports suitable for cable loop-through.
Features and Benefits
▪ Flame-retardant, impact-resistant engineering plastic and IP54
Can be mounted indoors or outdoors, ensuring a weather-resistant seal that protects against harsh environmental conditions
▪ Lock system
Can be locked by key lock or side hasp.
▪ Cable fixing system
A metal comb and hose clamp used to fasten the cable sheath.
▪ Mocro Splitter
Suitable for micro PLC splitter 1x8, 1x16.and 1x32
| Part No. | KW-FTB286 |
| Dimensions (mm) | 329×286×108 |
| Entry ports and cable dia. (max.) | 8×φ15mm |
| Splice capacity each tray | 12/24 FO |
| Max. number of splice tray | 6 |
| Splice capacity of the box | 72/144 FO |
| Possible for PLC splitter | 1x8, 1×16 , 1x32 micro splitter |
| Mounted way | Wall-mounted or pole-mounted |
