Connectors Interface
| 1 | According to | 4.3/10 |
Electrical
| 1 | Characteristic Impedance | 50ohm |
| 2 | Frequency Range | DC-6GHz |
| 3 | VSWR | ≤1.15(DC-4GHz) ≤ 1.2(4GHz-6GHz) |
| 4 | Dielectric Withstanding Voltage | ≥ 2500V |
| 5 | Dielectric Resistance | ≥5000MΩ |
| 6 | PIM3 | ≤ -160dBc |
Mechanical
| 1 | Durability | Mating cycles ≥500 |
Material and plating
|
| Description | Material | Plating |
| 1 | Body | Brass | Tri-alloy |
| 2 | Insulator | PTFE | – |
| 3 | Center conductor | Brass | Ag |
| 4 | Gasket | Silicon rubber | - |
| 5 | Other | Brass | Tri-alloy |
Environmental
| 1 | Temperature Range | -40℃~+85℃ |
| 2 | Waterproof | IP67 |
1.CNC machines ,advanced test equipment
2.All products are suit for ROHS.
3.ISO14001 certificate,ISO9001 certificate
