Pre-birdproofed cable assembly with 4.3-10 connector on both sides

A Pre-birdproofed Cable Assembly aims to protect coaxial cable against damage from birds.This jumper is made of feeder cable, connector and sheath. The sheath has three layers.Inner adopts galvanized steel strip; middle adopts PVC ultraviolet resistant, anti-aging; outer adopts stainless steel metal wire. The outer layers layer is mesh-shaped.
Quantity:

 Features/Benefits

  • Excellent bird-pecking resistant performance
  • High pull-off strength
  • Excellent V.S.W.R performance.
  • Low and stable intermodulation.
  • Weatherproof



Item No.        Description
BP1/2S-1-4310M--4310M 1/2 superflex pre-birdproofed jumper cable with 4.3-10 Male connector on both sides,
cable length 1 meter.
BP1/2S-1-DM--DM 1/2 superflex pre-birdproofed jumper cable with DIN Male connector on both sides,
cable length 1 meter.



    1.Elaborate interface design,sheath size from Ø4mm to Ø180mm. Cable and connector can be matched according to the needs of your base station Antenna. (N type, 7/16 type, 4.3-10, 4.1-9.5 type)

    2.There are various well-design solution for you to choose,
as long as one email or one call.


  Structure



Sheath material:

  • (inner) adopting galvanized steel strip
  • (middle) adopting PVC ultraviolet resistant, anti-aging
  • (outer) stainless steel metal wire

Product property: The product has excellent waterproof, insulating properties.



Application: The utility model belongs to the field of the cable, in particular to protect RF coaxial cable against bird pecking.
