1. 6 fiber cable in-out round ports(4 round ports,1 elliptical port)
Oval port for midspan installation
2. Suitable for aerial, duct,and underground application
3. Valve option for pressure testing
4. Engineering plastic body filled with silicon rubber and sealed with hoop,
the entry ports are sealed with heat shrinkable tube
5.Quick open clamped dome-base design
6. Reliable gasket sealing,reopened repeatedly without changing sealing material.
7. Suitable for ribbon and non-ribbon fibers
Dimension:540x Φ210
Cable diameter: Φ7-22 mm
Cable entry ports: six cables
Max capacity of fiber splice: 24(single) 72(ribbon)
Max capacity of splice tray: 4
Max capacity: 96(single), 288(ribbon)
Sealing structure:silicon gum material
Structure of cable entry port: heat-shrinkable sealing structure
1. 6 fiber cable in-out round ports(4 round ports,1 elliptical port)
Oval port for midspan installation
2. Suitable for aerial, duct,and underground application
3. Valve option for pressure testing
4. Engineering plastic body filled with silicon rubber and sealed with hoop,
the entry ports are sealed with heat shrinkable tube
5.Quick open clamped dome-base design
6. Reliable gasket sealing,reopened repeatedly without changing sealing material.
7. Suitable for ribbon and non-ribbon fibers
Dimension:540x Φ210
Cable diameter: Φ7-22 mm
Cable entry ports: six cables
Max capacity of fiber splice: 24(single) 72(ribbon)
Max capacity of splice tray: 4
Max capacity: 96(single), 288(ribbon)
Sealing structure:silicon gum material
Structure of cable entry port: heat-shrinkable sealing structure
Kunshan Kewei Fiber Communcations Equipment Co.,Ltd.
